Important quality control
* Built-in kidney bridge, more convenient and nice appearance.
* Be suitable for both x-ray and c-arm use.
* Morden appearance design
* Extra-long horizontal sliding, available for c-arm operation.
* All function controlled by hand controller and controller in the column, and can be locked.
Technical parameters
Technical configuration
* Built-in kidney bridge, more convenient and nice appearance.
* Be suitable for both x-ray and c-arm use.
* Morden appearance design
* Extra-long horizontal sliding, available for c-arm operation.
* All function controlled by hand controller and controller in the column, and can be locked.
Technical parameters
External LxWxH | 2060x500x(710-1010)mm |
Reverse trendelenburg | 0-25° |
Trendelenburg | 0-25° |
Lateral tilt left/right | 0-15° |
Head plate up/down | 0-40°/0-90° |
Back plate up/down | 0-80°/0-20° |
Leg plate up/down | 0-15°/0-90° |
Kidney bridge up | 110mm |
Horizontal sliding C type arm | 350mm |
Lowest position of table top | 710mm |
Highest position of table top | 1010mm |
Right lateral tilt | 0-20° |
Left lateral tilt | 0-20° |
Technical configuration
Bed frame | 1pc |
Mattress | 1set |
Anesthsia screen frame | 1pc |
Shoulder holder with cushion | 2pcs |
Arm holder with cushion | 2pcs |
Leg support with cushion | 2pcs |
Foot support with cushion | 2pcs |
Hand controller | 1pc |
Kidney bridge handle | 1pc |
Battery standby time(h) | 80 |
Power supply | 220V 50HZ 350VA |
Power control circuit | 12V |
Plug | as required |
